TP-Link TL-SG105MPE 5-port Gigabit Easy Smart Switch , 4895252500264

TP-Link TL-SG105MPE 5-Port Gigabit Easy Smart Switch with 4 PoE+ Ports

• Five 10/100/1000Mbps RJ45 ports
• Equipped with four 802.3af/at PoE+ ports with up to 30W per port, data and power can be transferred over a single cable
• Supports PoE power up to 120W for all PoE ports*
• Provides network monitoring, traffic prioritization, VLAN functions, and PoE auto-recovery
• Easy network setup in addition to plug-and-play connectivity
• Web-based user interface and Easy Smart Configuration Utility simplify configuration
• Fanless design reduces power consumption and eliminates noise when work

Multiple Application Scenarios
TL-SG105MPE is fully compatible with PoE devices, such as IP cameras, access points and IP phones. It also works
with non-PoE wired devices, such as computers, printers and IPTV.

Surveillance
Works with IP cameras

Conference call
Works with IP phones

Wi-Fi coverage
Works with Omada EAP

Wired connections
Works with computers and printers

Dedicated 4 PoE+ ports (120W budget) for multiple applications
Compliant with 802.3af/at PoE+ standard supports up to 30W on each PoE port. The total budget of 120 W PoE power* for 4× Gigabit PoE+ ports makes it suitable for a wide range of applications, such as surveillance, offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, etc.

Easy to use

Value-added features bring unexpected experiences

QoS for lag-free experience
Ensures smooth traffic for delay-sensitive applications such as voice and video

IGMP Snooping for multicast optimization
Ensures a better network experience, especially for applications such as IPTV, by optimizing the delivery of multimedia traffic.

Security VLAN
Helps create a network with higher security and better overall performance by dividing the network into smaller groups

Easy to manage
TL-SG105MPE offers network monitoring for users to monitor traffic behavior. Through its web-based user interface and management utility, TL-SG105MPE offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.

Multiple factors ensure stable operation
System self-healing with PoE auto-recovery
The switch automatically detects and restarts PD devices, such as cameras and access points, when they go offline or stop responding, ensuring stable operation of PoE-connected devices without the need for manual monitoring and restarting.

Supports PoE power up to 30W for each PoE port
Compliant with 802.3af/at PoE+ standard supports up to 30W for each PoE port. It is fully compatible with more 802.3at PD devices.

Great Compatibility with PD Detection
Automatically detects the required PoE power for your device and protects your non-PoE equipment from damage.

Long Product Life with Durable Metal Housing
The internal components of the TL-SG105MPE are protected by a high-quality metal housing to ensure product durability. Having passed a series of rigorous reliability tests, the TL-SG105MPE delivers switching performance you can rely on.

Package Contents

• TL-SG105MPE
• Power Adapter
• Installation Manual
• Rubber Feet
